HF27JZB02 Aviation Pallet Dolly (27 Ton Heavy… | Aviatrading

HF27JZB02 Aviation Pallet Dolly (27 Ton Heavy Duty) Heavy Duty Airport Ground Support Equipment for Wide Body Aircraft Cargo Handling

Published Jul 9, 2026| 97 views

Standard classification:Ground support equipment—Container & Pallet Dollies

Code

HF27JZB02

Condition

FN - Factory New

Type

Other

Brand

Hangfu

No certificates declaredThis part may be sold for non-airworthy use only (display, training, salvage, parts harvest). Verify documentation with the seller before purchase.

Return period

7

Return shipping paid by

Receiver

Additional note

30%deposit 70% balance before shipment Pre Order

Quantity

1 available

Seller information:

AIRDROME EQUIPMENT

120 items in stock

Item cost (1) $ 13,080

Shipping (per item)Upon Request

Total$ 13,080

This item can’t be purchased until shipping is confirmed. Submit a shipping request and the seller will review delivery options and costs.

Specifications & Details

Seller information:

AIRDROME EQUIPMENT

120 items in stock

The HF27JZB02 aviation pallet dolly is a high-capacity airport ground support equipment solution designed for heavy duty cargo handling in modern airport logistics systems. With a maximum load capacity of 27,000 kg, this aviation cargo dolly is suitable for wide body aircraft pallet transport, large cargo hubs, and high-throughput airport ground handling operations. Its reinforced #20 channel steel frame, combined with a swivel caster + roller platform system, ensures stable, flexible, and efficient cargo movement in demanding airside environments. Key Features & Benefits 27 Ton Heavy Duty Load Capacity Supports up to 27,000 kg payload Designed for heavy duty airport cargo transport Suitable for wide body aircraft ground handling operations Swivel Caster + Roller Platform System Equipped with COLSON swivel casters + 16 galvanized rollers Enables smooth pallet transfer with reduced friction Improves flexibility in airport cargo handling equipment workflows 6-Set Swivel Steering System Front axle includes 6 sets of swivel casters Provides excellent maneuverability for large equipment Suitable for airport ramp equipment and tight operating areas Reinforced #20 Channel Steel Structure Channel steel + pipe welded frame construction High resistance to impact and deformation Designed for continuous heavy duty GSE equipment use Rear Loading Design for Cargo Systems Rear-loading configuration Compatible with conveyor-based cargo handling systems Optimized for airport cargo terminal operations Advanced Safety Restraint System Movable brake limiter Fixed side limiters Spring-loaded pallet stoppers Prevents pallet displacement or derailment during transport Heavy Duty Solid Rubber Tire System Tire size: 266×160 / 400×133 Solid rubber construction for long service life Suitable for continuous heavy-load airport use Multi-Trailer Connection & Braking Tow bar supports multi-unit towing and braking Suitable for long-distance airport cargo transfer Works with baggage tug and towing systems Wide ULD Pallet Compatibility Supports standard aviation pallets: P1P, P6P PLA, FQA, FQW, PMW, P7E Suitable for wide body aircraft cargo logistics systems

Item Specification Platform Dimensions 6692 × 2726 mm Platform Height 520 mm Loading Capacity 27,000 kg Speed Limit 25–30 km/h Frame Material #20 channel steel + steel pipe Platform System Swivel casters + rollers Tire Type Solid rubber tires Tire Size 266×160 / 400×133 Tow Bar #10 channel steel Platform Surface 3 mm patterned steel plate Applications Airport cargo terminal operations Wide body aircraft cargo handling Air freight logistics systems High-volume airport cargo transport Integrated airport ground support equipment fleets
